Titan PowrCoat™ 745 Air Powered Spray

PowrCoat™ 745 Air Powered Spray

POWRCOAT™ sprayers are great for virtually any application, including architectural, finishing, industrial maintenace, corrosion control, cold applied roofing, waterproofing, and marine protective coatings.

Spray Features

• Severe Service: Hard-chrome polished piston and cylinders give long life.
• Tungsten carbide valve seats with hardened steel check balls provide better performance and durability.
• PowrCoat™ piston is engineered to provide unmatched chemical and solvent resistance while creating an ultra-smooth surface that operates with a smooth stroke that provides less friction and wear.
• Pumps are designed for easy application of today’s low-VOC, high solids, and abrasive coatings.
• Aircare System: Complete FRL (Filter, Regulator, Lubricator) standard with every PowrCoat. Eliminates motor icing.
• Automatic draining moisture trap. Easy access air filter & lubrication reservoir.
• Anti-icing motor ensures continuous operation
• Proven spool valve design with only five moving parts
• High efficiency air motor
• Long-life packings Severe Service™ pump
• Large 16” pneumatic wheels
• Integrated wall mount bracket
• Heavy duty cart
• Hose wrap and gun holder
• Heavy duty crane hook
• Lubrication adjustment for versatile use
• High capacity outlet filter reduces tip plugging
• Lift handles

Spray Specifications

• Air Motor Diameter: 7
• Ratio: 45:1
• Stroke Length: 4
• Max Operation Pressure: 4500 PSI
• Max Air Input Pressure: 100 PSI
• Max Recommended Air Volume Requirements: 102 CFM
• Fluid Output Recycle: 114 CC
• Max Recommended Output: 2.8 GPM

Click Here To Download The PowrCoat™ 745 User Manual
